Technical Specifications (W1-5K-G3 Model)
• Max. Efficiency: 97.5% – 97.8%
• Input (DC): Max 600V input with a start-up voltage of 120V.
• MPPT Range: Wide range of 90V – 580V with dual MPPT trackers.
• Output (AC): Nominal output of 5000W with a max output current of 23.9A.
• Protection: Integrated Type II Surge Protection (SPD) on both AC and DC sides, plus IP65
weatherproofing.
• Communication: Supports Wi-Fi, GPRS, and RS485 for real-time remote monitoring via the Waaree
app.
• Operating Temp: Rated for performance between -25°C to 60°C, optimized for Indian climatic
conditions.
WAAREE INVERTER TECHNICAL SPECIFICATION & IMAGE
Technical Specifications (Typical 5kW Single-Phase Model)
Input (DC)
• Recommended Max. PV Power: 7.5 kW (allows for 150% DC oversizing)
• Max. Input Voltage: 600V
• Rated Voltage: 360V
• Start-up Voltage: 120V
• MPPT Voltage Range: 90V – 550V
• Number of MPPTs: 2
• Max. Input Current per MPPT: 15A (compatible with high-current modules)
Output (AC)
• Rated Output Power: 5 kW
• Max. Output Power: 5.5 kVA
• Rated Grid Voltage: 220V / 230V / 240V
• Grid Frequency: 50Hz / 60Hz
• Max. Output Current: 23.9A
• Total Harmonic Distortion (THDi): < 3%
• Power Factor: > 0.99 (adjustable from 0.8 leading to 0.8 lagging)
Efficiency & Protection
• Max. Efficiency: ~98.1%
• European Efficiency: ~97.5%
• Protection Rating: IP65 (suitable for outdoor installation)
• Safety Features: DC Reverse Polarity Protection, AC Short Circuit Protection, Output Overcurrent
Protection, Surge Protection (Type II DC & AC), and Anti-islanding Protection.
General Data
• Cooling: Natural convection (fanless design for quiet operation)
• Display: LCD or LED indicators with App-based monitoring
• Communication: RS485, Wi-Fi, or GPRS
• Weight: Approximately 11–13 kg (varies by specific series)
ADANI INVERTER TECHNICAL SPECIFICATION & IMAGE
Feature Specification Details
Rated Output Power 5,000 Watts (5kW)
Max. DC Input Power 7,500 Watts (Supports 150% DC overloading)
Max. Input Voltage 600V
MPPT Operating Range 90V – 550V
Nominal Output Voltage 220V / 230V / 240V (Single Phase)
Cooling System Natural Convection (Fanless/Noiseless)
Weight Approximately 12.5 kg
Warranty Typically 5 to 10 years (standard industry terms)
