Feature Specification

• System Capacity: 5 kWp (Kilowatt peak)
• Module Type: Mono PERC Half-Cut / Bifacial
• Individual Panel Wattage: 545W – 550W
• Module Efficiency: Up to 21.11%
• Open Circuit Voltage (Voc): ~49.75 V
• Short Circuit Current (Isc): ~13.93 A
• Maximum System Voltage: 1500 V DC
• Operational Temperature: -40°C to +85°C
• Glass: 3.2mm high transmission, AR coated tempered glass
• Protection: IP68 rated junction box with 3 bypass diodes
