Technical Specifications (Typical 5kW Setup)
Feature Specification

• System Capacity: 5 kWp (Kilowatt peak)
• Module Type: Monocrystalline / Bifacial TOPCon
• Individual Panel Wattage: 545W – 600W
• Module Efficiency: Up to 23.26%
• Number of Cells: 144 Half-Cut Cells
• Dimensions: 2277 mm x 1133 mm x 35 mm
• Temperature Coefficient: -0.29 %/°C (Excellent for hot climates)
• Protection: IP68 Rated Junction Box
• Warranty: 12-year product warranty; 30-year power output warranty
